Name: ALR121-S01 YOKOGAWA Multipoint Serial Communication Modules Field Control Station ESB Bus Node Unit
Brand: Joyoung International Trading Co.,Ltd
SKU: ALR121-S01
Price: 4,690.00 USD
Availability: InStock

Home Products Yokogawa DCS

ALR121-S01 YOKOGAWA Multipoint Serial Communication Modules Field Control Station ESB Bus Node Unit

Product Details:

Place of Origin:	Singapore
Brand Name:	Yokogawa
Certification:	CO
Model Number:	ALR121-S01

Payment & Shipping Terms:

Minimum Order Quantity:	1 Piece
Price:	inquiry
Packaging Details:	original
Delivery Time:	3-5 working days
Payment Terms:	T/T
Supply Ability:	10 Piece per a day

Contact Now

Detailed Product Description

Product Model:	ALR121-S01	Condition:	In Stock
Quality:	New And Original	Market:	Worldwide Market
Material:	Original	Lead Time:	IN STOCK
Shipping Terms:	UPS / DHL / TNT / EMS / Fedex	Gross Weight:	2kg
Packing Size:	6" X 4" X 2" (15 Cm X 10 Cm X 5 Cm)
Highlight:	YOKOGAWA Multipoint Serial Communication Modules , ALR121-S01 ESB Bus Node Unit

ALR121-S01 YOKOGAWA Multipoint Serial Communication Modules Field Control Station ESB Bus Node Unit

Description:

An FCS collects data from subsystems or sets data with control calculations to subsystems using the builder functions by way of serial communication modules.

A communication module selects only one communication function, thus two ports must have identical communication functions. It is not possible to select different communication function for every port. The communication functions and those transmission speeds for each communication module are as shown in the table below.

ALR121-S01 YOKOGAWA Multipoint Serial Communication Modules Field Control Station ESB Bus Node Unit 0

This document describes about Models ALR111 and ALR121 Serial Communication Modules (for N-IO/FIO) that a field control station (FCS) uses to perform serial communication with subsystems such as FA-M3.

Additional Information:

Features
Interface	RS-422/RS-485
Connection method	Point-to-point (RS-422) Multipoint (RS-485)
Communication function	Half-duplex
Synchronization method	Start-stop synchronization
Transmission speed	1200/2400/4800/9600/19200/38400 bps
Transmission code	ASCII/binary
Character length	7/8 bits
Stop bit length	1/2 bits
Parity check	None/even/odd
Lag time after data transmission	1 ms (The lag time to start receiving data again after data transmission.)
Transmission distance	Maximum 1200 m (total extended length)
I/O wiring	Cable with 3-pair shield, AKB161, or AKB162
Wiring connection	Clamped with terminal block’s M4 screws (5 poles x 2)
Current consumption	0.5 A

Product Details:

Brand Name	YOKOGAWA
Model	ALR121-S01
Condition	New
Gross Weight/Shipping Weight	2.2 lbs / 35.2 oz / 1kg
Packing Size	6.4" x 6.4" x 4.8" (16cm x 16 cm x 12 cm)
Country of Origin/Original Country	United States (USA)
Lead Time	In Stock
Shipping Port	Xiamen
Payment	T/T
Sales Price	Inquiry
Color	Depend on product
Warranty	12 months
Lead time	5-8 work days
Courier partners	DHL, UPS, TNT, FedEx and EMS
