SDV541-S53 YOKOGAWA Digital Onput Module 16-Channel Module Isolation 24 V DC

SDV541-S53 YOKOGAWA Digital Onput Module 16-Channel Module Isolation 24 V DC

Description:

Output modules output on/off status signals to field equipment. The output modules can be made dual-redundant respectively.

This model incorporate field wiring diagnostic functions, so they require no wiring diagnosis elements.

The Yokogawa SDV541-S53 is a sophisticated and reliable solenoid-operated valve specifically designed for demanding industrial applications.

This valve is part of Yokogawa's extensive range of products known for their precision, durability, and superior performance in controlling fluid flow in various processes.

These voltages show the case using the field power supply floating. When the field power supply is grounded, the system (functional) ground is connected to the field ground, which is not isolated. For the higher noise immunity, floating the field power supply is recommended.

• When the withstanding voltage of the field power supply between the secondary side and the ground is lower than the value shown in the table above, these voltages are adopted as the withstanding voltage of the field power supply.
• Number of output channels which a user can use and maximum load current are restricted in case of SDV531-L£C. Refer to “ProSafe-RS Outline of I/O Modules (for FIO)” (GS 32P06K60-01EN).
• External power supply of SDV531-S style code S1 and S2 is 24 V DC ± 5%.
• Do not exceed this value, including the case of inrush/variation of the load current.
• Resistance value of the load for both ON and OFF state, including the field wiring resistance.
• When connecting SDV531 and SED4D terminal board using AKB331 dedicated signal cable, the withstand voltage is 500 V AC (between output signal lines and system). If MIL connector cables are used, the withstand voltage depends on their cable’s electrical specifications
• AKB651 can be used for connection with SDV531-L only

Product Details:

Additional Information:

Datasheet Link:Yokogawa SDV541-S53.pdf
