70EA01B-ES HESG447307R1 ABB Analog Input Module

70EA01B-ES HESG447307R1 ABB Analog Input Module

Product Details:

Additional Information:

Description:

The 88QT03 bus coupling module is used to connect PROCONTROL P to the bus of the PROCONTROL ---PS protection system. The following PROCONTROL ---PS modules can be connected:

--- 70EA01-ES/R1 Analog input module (one data telegram per function unit)

--- 70EA02-ES/R1 Analog input module (one data telegram per function unit)

--- 70EB02-ES/R4 Binary input module (one data telegram per module)

--- 70AB01-ES/R2 Binary output module (one data telegram per module)

--- 70PR03-ES/R2 Computing module

--- 70BK03-ES/R2 Bus coupling module (RS485 interface)

--- 70BT01/R1 Bus isolation amplifier

--- 70BV01-ES/R1 Bus control module

This module can be plugged into any multi-purpose processing station of the PROCONTROL bus system. It requires a space of 2 divisions. It transfers data from PROCONTROL-PS station modules to the station bus.

It transfers data received from the station bus to modules connected to the PROCONTROL-PS bus. The connected PROCONTROL ---PS modules are monitored for proper functioning.

Datasheet Link:ABB PROCONTROL.pdf
