3500/15-04-04-00 133300-01 Bently Nevada Legacy Low Voltage DC Power Input Module

3500/15-04-04-00 133300-01 Bently Nevada Legacy Low Voltage DC Power Input Module

Product Details:

Additional Information:

Description:

The 3500/15 AC and DC power supplies are low-profile modules and must be installed on the left side of the rack in designated slots. The 3500 rack can contain one or two power supplies providing any combination of AC and DC. Either supply can power the entire rack.

3500/15 AXX - BXX - CXX

A: Power Supply Type (Top Slot)

 01 Low Voltage AC (85 to 132 Vac rms)

 02 High Voltage AC (175 to 264 Vac rms)

 03 High Voltage DC (88 to 140 Vdc)

 04 Low Voltage DC (20 to 30 Vdc

 05 Universal AC Voltage (85 to 264 Vac rms)

B: Power Supply Type (Bottom Slot)

 00 No supply (Used when no supply is required)

 01 Low Voltage AC (85 to 132 Vac rms)

 02 High Voltage AC (175 to 264 Vac rms)

 03 High Voltage AC (88 to 140 Vdc)

 04 Low Voltage AC (20 to 30 Vdc)

 05 Universal AC Voltage (85 to 264 Vac rms)

C: Agency Approval

 00 None

 01 CSA / NRTL / C (Class 1, Division 2)

 02 ATEX / IECEx / CSA (Class 1, Zone 2)

Datasheet Link:Bently Nevada 3500 15.pdf
