DS200SSBAG1A GE Drive Snubber Board Mark V PCB Turbine Control System Series

DS200SSBAG1A GE Drive Snubber Board Mark V PCB Turbine Control System Series

Description:

The GE DS200SSBAG1A drive snubber board is designed for GE control systems and is primarily used to suppress high voltage spikes generated when the motor starts and stops.

This function effectively protects other components of the control system, reduces electrical interference, and improves the stability and reliability of the overall system.

• Connector and Capacitors: The GE DC300 Drive Snubber Board features a 2-pin connector and three capacitors. The 2-pin connector is used for connecting specific cables, while the capacitors serve important functions within the board's circuitry.
• Terminal Posts: The board is equipped with four posts for attaching cables. Three of these posts are designed to connect to cables attached to a component on the board. The factory provides printed materials that guide the proper attachment of the cables to the terminals.
• Cable Identification: During the replacement process, it is essential to examine the cables on the defective board and ensure that the cables on the replacement board are attached to the same terminals. If there is a fourth cable attached to the defective board, it should be tagged with the ID of the corresponding terminal.
• Efficient Cable Attachment: If there is a cable attached to the 2-pin connector, it is recommended to tag the cable with the connector ID printed on the board. This labeling ensures a faster and easier attachment of the cable to the replacement board.
