Description:

General Electric Speedtronic Mark VI IS200TDBSH6A is a Discrete Simplex Card and large printed circuit board. A group of twelve rectangular black components is mounted in the center of the PCB. These components were organized into three rows, each with four components. A lengthy grey component surrounds these black components on both sides.

The IS200TDBSH6A is a relatively large printed circuit board. Sitting on the upper half of the IS200TDBSH6A in the center is a series of twelve rectangular black components.

These components have been arranged into three rows of four components each. These black components are bordered on either side by a long grey component.These grey parts are long and rectangular. Two large terminal blocks are seen sitting along the left edge of the IS200TDBSH6A.

Every terminal has been numbered one through forty-eight in white letters. On the left border, these terminal blocks are vertically aligned. One mid-sized connector port with many extremely small female connections is located on the component’s opposing edge.
