IS200DAMBG1A GE IGBT Gate Driver Amplifier Passive Interface Board

IS200DAMBG1A GE IGBT Gate Driver Amplifier Passive Interface Board

Product Details:

Additional Information:

Description:

IS200DAMBG1A is a Gate Driver Board manufactured and designed by General Electric as part of the Mark VI Series used in GE Drive Control Systems. A gate driver board is an electronic circuit board used to control the switching of power semiconductor devices, such as MOSFETs, IGBTs, or SiC devices. It provides a low voltage signal to the gate of the power device to turn it on or off and is designed to drive the gate capacitance quickly and efficiently. Gate driver boards are commonly used in power electronics applications, such as motor drives, inverters, and power supplies. They are typically designed to provide high-current pulses to the gate of the power device, with fast rise and fall times to minimize switching losses and improve efficiency.

The IS200DAMBG1A was made as a component in the Speedtronic Mark VI series by General Electric or GE. The Mark VI is one of several series in GE’s Mark line. This device is a type of printed circuit board or PCB. The IS200DAMBG1A is what is called a gate driver card. The Innovation Series 200DAM Gate Drive Amplifier and Interface boards(DAM) provide an interface between the control rack and the power switching devices (IGBTs) of an Innovation Series low voltage drive. They include LEDs that indicate the IGBT on/off status. IS200DAMBG1A drive power rating is 375 frame, IS200DAMBG1ACB amplify current to provide the final stage of gate drive for one phase leg of the drive's power bridge.

The IS200DAMDG2A is a Gate Drive Interface Board developed by General Electric for use in their Mark VI Series of GE Drive Control Systems. The IS200DAMBG1ABB board was designed and shipped by General Electric. The IS200DAMBG1ABB board is a gate driver board and is part of the Innovation Series 200DAM Gate Drive Amplifier Interface Boards, which is a series that was designed to be inputted into the GE Mark VI SPEEDTRONIC series of products. The broader Mark VI Turbine Control System Series that this IS200DAMBG1ABB product offering belongs to, as it is known at length, exists with a set of specific applications in the control and management systems of General Electric-aligned gas, steam, and even wind turbine automated drive assemblies, which is a massive upgrade upon the previously-released Mark V Turbine Control System Series of the same full extended series title essentially.

This IS200DAMBG1ABB device's Mark V Series is additionally desirable due to its status as one of the final-developed GE Mark product series to implement the patented Speedtronic control system technology into a number of different product offerings. As a board included in the Innovations Series 200DAM_ Gate Drive Amplifier Interface Boards, the IS200DAMBG1ABB board provides a convenient interface between a control rack interface and a power switching device, which are called the IGBTs.

• 620 frame DAMA Board
• 375 frame DAMB Board
• 250 frame DAMC Board
• G1 for 180 frame, G2 for 125, 92 for G2 frame DAMD Board
• 65 frame DAME Board
