IS200CABPG1B GE Control Assembly Backplane Board Mark VI Turbine Control Module

IS200CABPG1B GE Control Assembly Backplane Board Mark VI Turbine Control Module

Product Details:

Description:

The IS200CABPG1B is a Control Assembly Backplane Board manufactured by General Electric as a part of the Mark VI series used in the gas turbine control systems. The IS200CABP Control Assembly Backplane(CABP) board is a multilayer printed wiring board that enables connectivity for printed wiring boards inserted into it as well as external signal interfaces. The number of boards installed depends on the power level and application of the Innovation Series drive to which the CABP board belongs.

External interfaces such as user control inputs/outputs (I/O), four front panel meters, diagnostic/configuration tools, a front panel keyboard, four ISBus ports, and power supply inputs are also accessible via connectors. The CABP board is mounted to the Innovation Series board rack, which has mounting points for each board. A single IS200HFPA High-Frequency Ac/Fan Power SupplyBoard powers the CABP board (HFPA). For the 48 V ac power, a twisted/shielded pair cable is used, and a separate isolated twisted pair cable is used for the 17 V ac power. These cables have a 1000 V dc isolation.

The IS200CABPG1B is a device called a control assembly backplane board. This device is a PCB or printed circuit board that was made to be part of the Speedtronic Mark VI series which was made by GE or General Electric. The Mark VI is just one of many different series in General Electric’s Mark line. The Mark VI Turbine Control System Series is something of a well self-described General Electric Mark product series offering, given the fact that it exists with a set of specific functional application in General Electric-compatible gas, steam, and even wind turbine automated drive assemblies. The IS200CABPG1B is a multi-layer printed wiring board. When printed wiring boards are inserted into the IS200CABPG1B, this device enables their connections. The IS200CABPG1B is an interface between external signals.

GE IS200CABPG1B control component backplane is a core circuit board designed for industrial automation systems, which is mainly responsible for connecting and supporting various control modules. Its design emphasizes reliability and durability, and can operate stably in harsh industrial environments. The backplane has good anti-interference ability, effectively reducing the impact of external noise on the signal and ensuring the accuracy of data transmission. In addition, the simple installation process and intuitive wiring identification enable operators to quickly configure and maintain the system.
