GE IS200BICIH1ACA Bridge Interface Controller Board Advanced Control Module

GE IS200BICIH1ACA Bridge Interface Controller Board Advanced Control Module

Product Details:

Description:

The IS200BICIH1A unit was manufactured and designed by General Electric and made to be a part of the GE Mark VI series. The IS200BICIH1A unit is classified as an interface card meant for use with the GE Mark VI series of SPEEDTRONIC Mark VI Turbine Control Systems, which is a system designed to completely integrate control, protection, and monitoring for generator and mechanical drive applications that operate gas and steam turbines.

The IS200BICIH1A interface card controls the interfaces for the General Electric SPEEDTRONIC Mark VI Turbine Control System. There is an I/O Interface and an Operator Interface. The aforementioned I/O interface is comprised of two versions of the unit’ s termination boards. The IS200BICIH1A unit was manufactured and designed by General Electric and made to be a part of the GE Mark VI series. The IS200BICIH1A unit is classified as an interface card meant for use with the GE Mark VI series of SPEEDTRONIC Mark VI Turbine Control Systems, which is a system designed to completely integrate control, protection, and monitoring for generator and mechanical drive applications that operate gas and steam turbines.

The IS200BICIH1A is a 5-Level H-Bridge Interface and Control Board manufactured and designed by General Electric as part of the Mark VI Series used in GE Speedtronic Control Systems. The BICH board is created to connect with 24 gate drivers, specifically for the Neutral-Point Clamped (NPC) H-bridge. Timers are integrated to facilitate two switching events in each gating period, covering all three H-bridges. The expected gating rate is 1.5 kHz. Similar to many models in the Mark VI Speedtronic series, it's important to note that this component is sensitive to static electricity and should be handled with utmost care. The board provides a versatile interface for seamless integration with H-bridge configurations.

The IS200BICIH1A offers precise control over the H-bridge system, allowing for tailored performance based on application requirements. It is designed to interface with multiple gate drivers, enhancing flexibility in system design and expansion.

The GE IS200BICIH1ACA Control Module is a high-performance component designed for industrial automation systems, specifically tailored for enhancing efficiency and precision in complex machinery operations. Engineered for robust industrial use, the GE IS200BICIH1ACA Control Module seamlessly integrates into complex control systems, ensuring seamless operation and reliability. This control module is equipped with AOCA Analog Comparator modules and DVAA Dual Voltage Controlled Oscillator Modules, providing precise signal processing and control functionality.
