GE IS220PDIIH1B Mark V Board Discrete Contact Input Terminal Board

GE IS220PDIIH1B Mark V Board Discrete Contact Input Terminal Board

Product Details:

Description:

The IS220PDIIH1B is a Discrete Contact Input Terminal Board manufactured and designed by General Electric as part of the Mark VIe Series used in GE Distributed Turbine Control Systems. The PDIA I/O pack provides the electrical interface between one or two I/O Ethernet networks and a discrete input terminal board. The pack contains a processor board common to all Mark VIe distributed I/O packs and an acquisition board specific to the discrete input function. The pack accepts up to 24 contact inputs and terminal board-specific feedback signals, and PDIA accepts three different voltage levels (with types TBCIH1, H2, and H3 terminal boards). Connections for the isolated discrete input board with voltage sensing (with type TICI board) are available.

Compared to other models in the Mark VI Series the IS220PDIAH1A does not necessarily have a specific faceplate as it is an I/O pack. On the front of the device, there are seven indicators, on the right side of the pack in a group of three there are indicators for the power and two for the link, one is indicated as ENet1, and the other ENet2. Underneath these three indicators, there is an Ethernet port which is used for cabling the model to the Ethernet to allow for easy Ethernet communication. It features high-speed, networked input/output (I/O) for simplex, dual, and triple redundant systems. Industry-standard Ethernet communications are used for I/O, controllers, and supervisory interface to operator and maintenance stations, as well as third-party systems.

The IS220PDIIH1B is labeled as a Discrete I/O Pack and is used in the Mark VI Series alongside the YDIA Discrete Input Module. The model works together with the PDIA to be approved for usage in hazardous locations. On the front of the device, there are seven indicators, including three indicators for the power and two for the link, labeled as ENet1, and ENet2. Underneath these three indicators, there is an Ethernet port which is used for cabling the model to the Ethernet to allow for easy Ethernet communication.

As GE PDIA Discreted Input module, IS220PDIIH1B is belong to Mark Vie series. The Discrete Input (PDIA) pack provides the electrical interface between one or two I/O Ethernet networks and a discrete input terminal board. The pack contains a processor board common to all Mark Vle distributed I/O packs and an acquisition board specific to the discrete input function. The pack accepts up to 24 contact input and terminal board specific feedback signals. PDIA accepts three different voltage levels (with types TBCIH1, H2 and H3 terminal boards). Connections fo rthe isolated discrete input board with voltage sensing (with type TICI board) are available. System input to the pack is through dual RI45 Ethernet connectors and a three-pin power input. Discrete signal input is through a DC-37 pin connector that connects directly with the associated terminal board connector. Visual diagnostics are provided through indicator LEDs, and local diagnostic serial communications are possible through an infrared port. The Mark VIe control system is a flexible platform used in multiple applications.
