GE IS215UCVGM06A Boards & Turbine Control Mark VI IS200 Industrial Control PLC

GE IS215UCVGM06A Boards & Turbine Control Mark VI IS200 Industrial Control PLC

Product Details:

Additional Information:

Description:

The IS215UCVGM06A module typically offers multiple universal input channels, allowing it to receive both current and voltage signals from a wide range of sources, such as sensors, transmitters, or other devices. The module supports specific current and voltage ranges, which may vary depending on the application requirements. It can accommodate a wide range of current and voltage levels, such as 4-20mA, 0-10V, or other specified ranges.

The module is typically designed for easy installation and integration into standard racks or cabinets. It may feature connectors or terminals for efficient wiring and connection with other devices.

I/O devices on the equipment can be mounted up to 300 meters (984 feet) from the boards, and the boards must be within 15m (49.2 feet) from their corresponding I/O boards. Normally, the boards are mounted in vertical columns in terminal cabinets with pre-assigned cable lengths and routing to minimize exposure to emi-rfi for noise sensitive signals such as speed inputs and servo loops.

The HMI can be reinitialized or replaced with the process running with no impact on the control system. The HMI communicates with the main processor board in the control module through the Ethernet-based Unit Data Highway (UDH). All analog and digital data in the Mark VI is accessible for HMI screens, including the high resolution time tags for alarms and events.

System (process) alarms and diagnostics alarms for fault conditions are time tagged at frame rate (10/20/40ms) in the Mark VI control and transmitted to the HMI alarm management system. System events are time tagged at frame rate, and Sequence of Events (SOE) for contact inputs are time tagged at 1ms on the contact input board in the control module. Alarms can be sorted according to ID, Resource, Device, Time, and Priority. Operators can add comments to alarm messages or link specific alarm messages to supporting graphics.

Data is displayed in either English or Metric engineering units with a one second refresh rate and a maximum of one second to repaint a typical display graphic. Operator commands can be issued by incrementing/decrementing a setpoint or entering a numerical value for the new setpoint. Responses to these commands can be observed on the screen one second from the time the command was issued. Security for HMI users is important to restrict access to certain maintenance functions, such as editors and tuning capability, and to limit certain operations.
