Name: X20CP1584 B&R Automation Plc 0.6 GHz CPU With 256 MB DDR2 SDRAM X20 System Module
Brand: Joyoung International Trading Co.,Ltd
SKU: X20CP1584
Price: 4,690.00 USD
Availability: InStock

Home Products B&R Automation Plc

X20CP1584 B&R Automation Plc 0.6 GHz CPU With 256 MB DDR2 SDRAM X20 System Module

Product Details:

Place of Origin:	Austria
Brand Name:	B&R
Certification:	COC
Model Number:	X20CP1584

Payment & Shipping Terms:

Minimum Order Quantity:	1EA
Price:	USD
Packaging Details:	Original
Delivery Time:	3-5 days
Payment Terms:	T/T
Supply Ability:	10EA

Contact Now

Detailed Product Description

Product Name:	B&R	Product Model:	X20CP1584
System Module:	CPU	Clock Frequency:	0.6 GHz
RAM:	256 MB DDR2 SDRAM	Warranty:	1 Year
Dimensions:	1509985 Mm	Weight:	400 G
Highlight:	X20CP1584 , 0.6 GHz CPU B&R Automation Plc , DDR2 SDRAM X20 System Module

X20CP1584 B&R 0.6 GHz CPU With 256 MB DDR2 SDRAM X20 System Module

General information

B&R ID code	0xC370
Cooling	Fanless
Status indicators	CPU function, Ethernet, POWERLINK, CompactFlash, battery
Diagnostics
Battery	Yes, using LED status indicator and software
CPU function	Yes, using LED status indicator
CompactFlash	Yes, using LED status indicator
Ethernet	Yes, using LED status indicator
POWERLINK	Yes, using LED status indicator
Temperature	Yes, using software register
Support
Controller redundancy	No
Storage health data support	Yes
ACOPOS support	Yes
Visual Components support	Yes
Power consumption without interface module and USB	8.6 W
Power consumption for X2X Link power supply	1.42 W
Power consumption
Internal I/O	0.6 W
Additional power dissipation caused by actuators (resistive) [W]	-
Certifications
CE	Yes
UKCA	Yes
ATEX	Zone 2, II 3G Ex nA nC IIA T5 Gc IP20, Ta (see X20 user's manual) FTZÚ 09 ATEX 0083X
UL	cULus E115267 Industrial control equipment
HazLoc	cCSAus 244665 Process control equipment for hazardous locations Class I, Division 2, Groups ABCD, T5
DNV	Temperature: B(0 - 55°C) Humidity: B(up to 100%) Vibration: B(4 g) EMC: B(bridge and open deck)
LR	ENV1
KR	Yes
ABS	Yes
EAC	Yes
KC	Yes

CPU and X2X Link power supply

Input voltage	24 VDC -15% / +20%
Input current	Max. 1.5 A
Fuse	Integrated, cannot be replaced
Reverse polarity protection	Yes

X2X Link power supply output

Nominal output power	7 W
Parallel connection	Yes
Redundant operation	Yes

Input I/O power supply

Input voltage	24 VDC -15% / +20%
Fuse	Required line fuse: Max. 10 A, slow-blow

Output I/O power supply

Nominal output voltage	24 VDC
Permissible contact load	10 A

Power supply - General information

Status indicators	Overload, operating status, module status, RS232 data transfer
Diagnostics
RS232 data transfer	Yes, using LED status indicator
Module run/error	Yes, using LED status indicator and software
Overload	Yes, using LED status indicator and software
Electrical isolation
I/O supply - I/O power supply	No
CPU/X2X Link supply - CPU/X2X Link power supply	Yes

Controller

CompactFlash slot	1
Real-time clock	Nonvolatile, resolution 1 s, -10 to 10 ppm accuracy at 25°C
FPU	Yes
Processor
Type	Atom E620T
Clock frequency	0.6 GHz
L1 cache
Data code	24 kB
Program code	32 kB
L2 cache	512 kB
Integrated I/O processor	Processes I/O data points in the background
Modular interface slots	1
Remanent variables	Max. 256 kB
Shortest task class cycle time	400 µs
Typical instruction cycle time	0.0075 µs
Data buffering
Battery monitoring	Yes
Lithium battery	Min. 2 years at 23°C ambient temperature
Standard memory
RAM	256 MB DDR2 SDRAM
User RAM	1 MB SRAM

Interfaces

Interface IF1
Signal	RS232
Variant	Connection via 12-pin terminal block X20TB12
Max. distance	900 m
Transfer rate	Max. 115.2 kbit/s
Interface IF2
Signal	Ethernet
Variant	1x RJ45 shielded
Line length	Max. 100 m between 2 stations (segment length)
Transfer rate	10/100/1000 Mbit/s
Transfer
Physical layer	10BASE-T/100BASE-TX/1000BASE-T
Half-duplex	Yes
Full-duplex	Yes
Autonegotiation	Yes
Auto-MDI/MDIX	Yes
Interface IF3
Fieldbus	POWERLINK (V1/V2) managing or controlled node
Type	Type 4
Variant	1x RJ45 shielded
Line length	Max. 100 m between 2 stations (segment length)
Transfer rate	100 Mbit/s
Transfer
Physical layer	100BASE-TX
Half-duplex	Yes
Full-duplex	POWERLINK mode: No / Ethernet mode: Yes
Autonegotiation	Yes
Auto-MDI/MDIX	Yes
Interface IF4
Type	USB 1.1/2.0
Variant	Type A
Max. output current	0.5 A
Interface IF5
Type	USB 1.1/2.0
Variant	Type A
Max. output current	0.5 A
Interface IF6
Fieldbus	X2X Link master

Electrical properties

Electrical isolation	Ethernet (IF2), POWERLINK (IF3) and X2X (IF6) isolated from each other, from other interfaces and from PLC

Operating conditions

Mounting orientation
Horizontal	Yes
Vertical	Yes
Installation elevation above sea level
0 to 2000 m	No limitation
>2000 m	Reduction of ambient temperature by 0.5°C per 100 m
Degree of protection per EN 60529	IP20

Ambient conditions

Temperature
Operation
Horizontal mounting orientation	-25 to 60°C
Vertical mounting orientation	-25 to 50°C
Derating	See section "Derating".
Storage	-40 to 85°C
Transport	-40 to 85°C
Relative humidity
Operation	5 to 95%, non-condensing
Storage	5 to 95%, non-condensing
Transport	5 to 95%, non-condensing

Mechanical properties

Note	Order application memory (CompactFlash) separately Backup battery included in delivery X20 end cover plate (right) included in delivery 12-pin X20 terminal block included in delivery Interface module slot covers included in delivery
Dimensions
Width	150 mm
Height	99 mm
Depth	85 mm
Weight	400 g

X20CP1584 B&R Automation Plc 0.6 GHz CPU With 256 MB DDR2 SDRAM X20 System Module 0
